Features:
Shallow Basket Design - With a shallow mounting depth of only 24mm [15/16"], the SM Series speakers are ideal for installation where mounting depth is limited.
Tuned, Sealed Enclosure Design - Protects the speakers' components from damage and ensures quality audio reproduction is delivered that normally could not be achieved by a speaker with such a shallow design.
Retrofittable - The SM Series speakers have a circular back with a mounting diameter clearance of 130mm [5-1/8"], allowing it to fit easily into existing 6.5" speaker cutouts.
Aesthetic Interior Design - Designed with aesthetics in mind, the SM Series come with a high-end acoustic fabric grille and feature rounded edges and contour cues to add style to your vessel.
IP65 Weatherproof - The SM Series speakers are rated IP65 for protection against dust and water ingress in the harsh marine environment.
Product Specifications
| Speaker Enclosure Size |
155mm x 155mm [6-1/8" x 6-1/8"] |
| Peak Power Rating |
100 Watts |
| Driver Size |
Tuned and optimized 3" |
| Efficiency (1W/1M) |
84 dB |
| Frequency Response |
150 Hz - 20 kHz |
| Nominal Impedance |
4 Ohms |
| Cone / Surround Material |
Polypropylene with rubber surround |
| Mounting Diameter Clearance |
130mm [5-1/8"] |
| Mounting Depth Clearance |
24mm [15/16"] |
| Operating Temperature Range |
0 to 50°C (32 to 122°F) |
| Storage Temperature Range |
-20 to 70°C (-4 to 158°F) |
| Water and Dust Resistance (IP rating) |
IP65 |
| Speaker Dimensions: Length x Height x Depth |
155mm x 155mm x 46mm [6-1/8" x 6-1/8" x 1-13/16"] |
| Warranty |
1 year |
